Planetary spiral bevel gearbox
Ratios of shaft d1
i=n1:n2= 1,66:1; 1,33:1; 1:1; 1:1,2; 1:1,5; 1:2; 1:3; 1:3,75
Ratios of shaft d2
i=n2:n1= 4,5:1; 3,75:1; 3:1; 2:1; 1,5:1; 1,2:1; 1:1; 1:1,33
Ratios of shaft d3
i= 135:1
12 gearbox sizes
Max. torque: 2500 Nm
Max. speed at shaft d1
1000 min-1
Max. speed at shaft d3
3000 min-1
Right-angle input and output
- Dimensions, performance data and further informations see our Speed modulation gearboxes-catalogue
- Inertia (pdf)
Using mutli-start worm gears, the speed modulation ratio may be reduced.
